Lyrebird E-Cycle
Lyrebird E-Speed 24 Inches Front
TECHNICAL SPECIFICATION
| Model Name & Spec | LYREBIRD E-Sposd 24 Inches Front |
|---|---|
| Colors Available | Black, Red, Green, White |
| Type of bike -city, mtb, hybrid | Electric/hybrid |
| Bike Frame Type | Steel |
| Frame Size | 16 Inches |
| Top Speed | 25km/hr |
| Range on PAS | NA |
| Range on Thererottle | Upto 32 km |
| Bike weight with battery | 32.5 kg |
| Bike weight without battery | 22 kg |
| Suspension | Telescopic |
| Gears | Single |
| Battery Type | Li-24V 11Ah, 800 cycles, 3 years |
| Motor Spacs and location | 24V, 250 watt BLDC motor (Front Drive) |
| Torque | NA |
| Charger details & charging time | 29V 3Ah (3.5-4 Hr) |
| Brakes-Front | Rim-U-Brake |
| Brakes-Rear | Disc Brakes |
| Details of brake lever | Aluminum |
| Throttle-Half/Full | Half with key set |
| IP specs | Battery IP 65 Controller, Sensor IP 67 |
| Display | Battery Level Indicator LED |
| Lights specs | NA |
| Tyres size and brand | 26 Inches Hartex |
| Mudguards | Dual tone |
| USP | Portable Aluminum casing Battery pack, Key switch start |
| Recommended customer height | 4.5-5.5 Feet |
| Recommended customer weight | 75 Kg |
| Pedals | Plastic |
| Seat | Broad |
| Seat post | Steel with quick adjustment |
| Material and Lenght of handle bar | Steel 69 Cm |
| Items included in the box | Frame, wheel, handle, Battery, Controller, Mudguards |
| Assembly | 85% assembled in box packiging |
| Warranty | Product has standard warranty Frame - Lifetime Battery-12 Month, Motor-12 Month, Controller-6 Month |
Lyrebird E-Cycle
Lyrebird E-Speed 26 Inches Front
TECHNICAL SPECIFICATION
| Model Name & Spec | LYREBIRD E-Sposd 26 Inches Front |
|---|---|
| Colors Available | Black, Red, Green, White |
| Type of bike -city, mtb, hybrid | Electric/hybrid |
| Bike Frame Type | Steel |
| Frame Size | 16 Inches |
| Top Speed | 25km/hr |
| Range on PAS | NA |
| Range on Thererottle | Upto 32 km |
| Bike weight with battery | 32.5 kg |
| Bike weight without battery | 22 kg |
| Suspension | Telescopic |
| Gears | Single |
| Battery Type | Li-24V 11Ah, 800 cycles, 3 years |
| Motor Spacs and location | 24V, 250 watt BLDC motor (Front Drive) |
| Torque | NA |
| Charger details & charging time | 29V 3Ah (3.5-4 Hr) |
| Brakes-Front | Rim-U-Brake |
| Brakes-Rear | Disc Brakes |
| Details of brake lever | Aluminum |
| Throttle-Half/Full | Half with key set |
| IP specs | Battery IP 65 Controller, Sensor IP 67 |
| Display | Battery Level Indicator LED |
| Lights specs | NA |
| Tyres size and brand | 26 Inches Hartex |
| Mudguards | Dual tone |
| USP | Portable Aluminum casing Battery pack, Key switch start |
| Recommended customer height | 4.5-5.5 Feet |
| Recommended customer weight | 75 Kg |
| Pedals | Plastic |
| Seat | Broad |
| Seat post | Steel with quick adjustment |
| Material and Lenght of handle bar | Steel 69 Cm |
| Items included in the box | Frame, wheel, handle, Battery, Controller, Mudguards |
| Assembly | 85% assembled in box packiging |
| Warranty | Product has standard warranty Frame - Lifetime Battery-12 Month, Motor-12 Month, Controller-6 Month |
Lyrebird E-Cycle
Lyrebird E-Speed 26 Inches Rear
TECHNICAL SPECIFICATION
| Model Name & Spec | LYREBIRD E-Sposd 26 Inches Rear |
|---|---|
| Colors Available | Black, Red, Green, White |
| Type of bike -city, mtb, hybrid | Electric/hybrid |
| Bike Frame Type | Steel |
| Frame Size | 16 Inches |
| Top Speed | 25km/hr |
| Range on PAS | NA |
| Range on Thererottle | Upto 32 km |
| Bike weight with battery | 32.5 kg |
| Bike weight without battery | 22 kg |
| Suspension | Telescopic |
| Gears | Single |
| Battery Type | Li-24V 11Ah, 800 cycles, 3 years |
| Motor Spacs and location | 24V, 250 watt BLDC motor (Front Drive) |
| Torque | NA |
| Charger details & charging time | 29V 3Ah (3.5-4 Hr) |
| Brakes-Front | Rim-U-Brake |
| Brakes-Rear | Disc Brakes |
| Details of brake lever | Aluminum |
| Throttle-Half/Full | Half with key set |
| IP specs | Battery IP 65 Controller, Sensor IP 67 |
| Display | Battery Level Indicator LED |
| Lights specs | NA |
| Tyres size and brand | 26 Inches Hartex |
| Mudguards | Dual tone |
| USP | Portable Aluminum casing Battery pack, Key switch start |
| Recommended customer height | 4.5-5.5 Feet |
| Recommended customer weight | 75 Kg |
| Pedals | Plastic |
| Seat | Broad |
| Seat post | Steel with quick adjustment |
| Material and Lenght of handle bar | Steel 69 Cm |
| Items included in the box | Frame, wheel, handle, Battery, Controller, Mudguards |
| Assembly | 85% assembled in box packiging |
| Warranty | Product has standard warranty Frame - Lifetime Battery-12 Month, Motor-12 Month, Controller-6 Month |
Lyrebird E-Cycle
Lyrebird E-Speed 27.5 Inches Rear
TECHNICAL SPECIFICATION
| Model Name & Spec | LYREBIRD E-Sposd 27.5 Inches Rear |
|---|---|
| Colors Available | Black, Red, Green, White |
| Type of bike -city, mtb, hybrid | Electric/hybrid |
| Bike Frame Type | Steel |
| Frame Size | 16 Inches |
| Top Speed | 25km/hr |
| Range on PAS | NA |
| Range on Thererottle | Upto 32 km |
| Bike weight with battery | 32.5 kg |
| Bike weight without battery | 22 kg |
| Suspension | Telescopic |
| Gears | Single |
| Battery Type | Li-24V 11Ah, 800 cycles, 3 years |
| Motor Spacs and location | 24V, 250 watt BLDC motor (Front Drive) |
| Torque | NA |
| Charger details & charging time | 29V 3Ah (3.5-4 Hr) |
| Brakes-Front | Rim-U-Brake |
| Brakes-Rear | Disc Brakes |
| Details of brake lever | Aluminum |
| Throttle-Half/Full | Half with key set |
| IP specs | Battery IP 65 Controller, Sensor IP 67 |
| Display | Battery Level Indicator LED |
| Lights specs | NA |
| Tyres size and brand | 26 Inches Hartex |
| Mudguards | Dual tone |
| USP | Portable Aluminum casing Battery pack, Key switch start |
| Recommended customer height | 4.5-5.5 Feet |
| Recommended customer weight | 75 Kg |
| Pedals | Plastic |
| Seat | Broad |
| Seat post | Steel with quick adjustment |
| Material and Lenght of handle bar | Steel 69 Cm |
| Items included in the box | Frame, wheel, handle, Battery, Controller, Mudguards |
| Assembly | 85% assembled in box packiging |
| Warranty | Product has standard warranty Frame - Lifetime Battery-12 Month, Motor-12 Month, Controller-6 Month |
